SPIDER
SPIDER
light-trail | 130mm suspension | 29" wheels
Build Your Spider, Your Way!
Start with the efficient Spider frame and bring your dream build to life. With our Frame First 3D Configurator, you choose every detail.
Oxblood red
Chalk White
Satin Grey
Not for the Faint of heart.
The new INTENSE Spider has arrived—reviving the “Trail Light” category within our lineup. Equipped with 29” wheels, 130mm of rear travel, and a recommended 130mm fork, this bike is built for versatility. More than just an update, the Spider is a completely reimagined carbon frame, developed from decades of experience and innovation. Whether you’re pushing for performance on long rides or seeking to smooth out dynamic terrain, the Spider is your ideal trail companion.
features
carbon fit
The Spider’s carbon layup is tailored to each frame size, optimizing strength, weight, and compliance for riders of all sizes. This ensures every rider experiences the perfect balance of stiffness and responsiveness.
JS TUNED
Incredibly smooth performance on mixed terrain with excellent pedaling efficiency. Supportive while climbing and on flatter trails, yet bottomless as the terrain gets rougher.
FRAME PROTECTION
The frame has integrated front and rear triangle protection to keep the bike looking like new. It also has an integrated rear fender to keep the shock clear of dirt and muck.
Accessory Mount
The Spider has a designated storage mount on the bottom of the top tube to hold tools, air canisters, tire levers and more.
THREADED BB
The Spider features a threaded BB. The preferred choice for riders who handle their own bike maintenance. Less prone to creaking, and better for reliable long term performance.
| FRAME SIZE | SM | MD | LG | XL |
| WEIGHT (NO SHOCK) | 5lbs 12oz / 2.3kg | 6lbs / 2.72kg | 6lbs 3oz / 2.8kg | 6lbs 6oz / 2.89 |
| SIZING | 5'0-5'6" | 5'4"-5'10" | 5'8"-6'2" | 6'1"-6'6" |
| REACH | 430mm | 455mm | 475mm | 505mm |
| HEADTUBE ANGLE | 65° | 65° | 65° | 65° |
| SEATTUBE ANGLE (Effective) | 78° | 78° | 78° | 78° |
| SEATUBE ANGLE (Actual) | 74° | 74° | 74° | 74° |
| WHEELBASE | 1177mm | 1206mm | 1230mm | 1264mm |
| CHAINSTAY LENGTH | 435mm | 435mm | 435mm | 435mm |
| BB HEIGHT | 336mm | 336mm | 336mm | 336mm |
| STACK | 602mm | 612mm | 620mm | 630mm |
| TOPTUBE LENGTH | 557mm | 585mm | 607mm | 639mm |
| HEADTUBE LENGTH | 100mm | 110mm | 120mm | 130mm |
| BB DROP | 38.5mm | 38.5mm | 38.5mm | 38.5mm |
| SEATTUBE LENGTH | 390mm | 415mm | 440mm | 465mm |
| MAX SEATPOST DEPTH | 215mm | 250mm | 275mm | 300mm |
*Based Off a 605mm axle to crown, 52mm offset fork // **Based off Front tire OD of 750mm, Rear tire OD of 711mm
