Bring your All-New Custom Tazer build to life, with our 3D Configurator
| TAZER WITH 279 REAR | SM | MD | LG | XL |
| Reach | 430mm | 460mm | 480mm | 505mm |
| Headtube Angle | 64.5° | 64.5° | 64.5° | 64.5° |
| Seattube Angle (Effective) | 77.9° | 77.9° | 77.9° | 77.9° |
| Seattube Angle (Actual) | 72.8° | 72.8° | 72.8° | 72.8° |
| Wheelbase | 1205.4mm | 1241.9mm | 1266.1mm | 1293.3mm |
| Chainstay Length | 445mm | 445mm | 445mm | 445mm |
| Front Center | 756mm | 792.5mm | 816.8mm | 843.9mm |
| BB Height | 342mm | 342mm | 342mm | 342mm |
| Stack | 614.3mm | 627.8mm | 636.8mm | 641.4mm |
| Toptube Length | 560.9mm | 595mm | 617.8mm | 644.2mm |
| Headtube Length | 100mm | 115mm | 125mm | 130mm |
| BB Drop Front Wheel | 33mm | 33mm | 33mm | 33mm |
| BB Drop Rear Wheel | 13mm | 13mm | 13mm | 13mm |
| Seattube Length | 405mm | 415mm | 445mm | 470mm |
| Max Seatpost Insertion Depth | (S) 220mm | (M) 230mm | (L) 250mm | (XL) 280mm |
*Based Off a 571mm axle to crown, 44mm offset fork // **Based off Front tire OD of 750mm, Rear tire OD of 715mm
| TAZER WITH 29 REAR | SM | MD | LG | XL |
| Reach | 430mm | 460mm | 480mm | 505mm |
| Headtube Angle | 64.5° | 64.5° | 64.5° | 64.5° |
| Seattube Angle (Effective) | 77.9° | 77.9° | 77.9° | 77.9° |
| Seattube Angle (Actual) | 72.8° | 72.8° | 72.8° | 72.8° |
| Wheelbase | 1206mm | 1242.5mm | 1266.8mm | 1293.9mm |
| Chainstay Length | 450mm | 450mm | 450mm | 450mm |
| Front Center | 756mm | 792.5mm | 816.8mm | 843.9mm |
| BB Height | 342mm | 342mm | 342mm | 342mm |
| Stack | 614.3mm | 627.8mm | 636.8mm | 641.4mm |
| Toptube Length | 560.9mm | 595mm | 617.8mm | 644.2mm |
| Headtube Length | 100mm | 115mm | 125mm | 130mm |
| BB Drop | 33mm | 33mm | 33mm | 33mm |
| Seattube Length | 405mm | 415mm | 445mm | 470mm |
| Max Seatpost Insertion Depth | (S) 220mm | (M) 230mm | (L) 250mm | (XL) 280mm |
*Based Off a 571mm axle to crown, 44mm offset fork // **Based off Front tire OD of 750mm, Rear tire OD of 750mm
| Model Year: 2027 |
| Category: E-Bike |
| Available Sizes: S, M, L, XL |
| Available Colors: Satin Blue, & UD Black |
| Frame Weight (No Shock): (S) TBD | (M) 24lbs 2 oz/ 10.94 Kg | (L) 24lbs 5 oz/ 11.03 Kg | (XL) TBD |
| Max Front Travel: 160mm |
| Max Rear Travel: 150mm |
| Non-Compatible Shocks: FOX Live Valve | RockShox Flight Attendant |
| Headset: ZS49 Upper/ ZS56 Lower |
| Seattube Diameter: 31.6mm |
| Seatpost Clamp: 36.1mm (Intense Collar Only) |
| Max Seatpost Insertion Depth: (S) 220mm | (M) 230mm | (L) 250mm | (XL) 280mm |
| BB Shell Width: N/A |
| Max Chainring: 34T |
| Chainline: 55mm |
| Recommended Max Tire Width: 2.5mm |
| Brakes: Disc Brake Hydraulic, Post Mount/ Direct |
| Min Brake Rotor Size: 200mm |
| Max Brake Rotor Size: 223mm (with adapter) |
| Derailleur Hanger: UDH |
| T-Type Compatible: Yes |
| Rear Hub Spacing: 12mm x 148mm Boost |
| Shock Size: 210mm x 55mm |
| Front Shock Mount Hardware: 8mm x 30mm |
| Rear Shock Mount Hardware: 8mm x 20mm |
| Motor | Motor: Bosch CX Gen 5, 120Nm |
| Control: Bosch System Controller | |
| Remote: Bosch Mini Remote | |
| Battery: Bosch 600Wh PowerTube | |
| Suspension | Fork: 2027, 38, FLOAT, 29in, 160, Grip, 3Pos, 15QRx110, 44mm offset |
| Shock: 2027, FLOAT X, Performance, 2pos, Evol LV, 210x55 | |
| Drivetrain | Derailleur: SRAM Eagle 70 Transmission, RD-70-A1 |
| Cassette: SRAM XS-1275, Eagle Transmission, 10-52 | |
| Crankset: SRAM S1000, 155mm Length, 34 Tooth | |
| Shifter: SRAM Eagle 70 Transmission, SL-70-A1 | |
| Chain: GX Eagle Transmission, CN-TTYP-GX-A1 | |
| Wheels | Wheelset: DT Swiss E 1900 |
| Front Hub: DT Swiss 370 | |
| Rear Hub: DT Swiss 370 | |
| Tires: Kryptotal F Enduro Casing, Soft Compound, 29" x 2.4" / Kryptotal R Enduro Casing, 27.5" / 29" x 2.4" | |
| Brakes | Brake Set: SRAM Maven Base |
| Rotors: SRAM HS2 Rotor, 200mm, 6-bolt | |
| Components | Headset: FSA Tazer Headset |
| Stem: RaceFace Chester, 35mm x 40mm, Black | |
| Handlebar: RaceFace Chester Alloy, 35mm x 35mm Rise, BLK, 780mm Width | |
| Seatpost: OneUp V3 Dropper Post (S)150mm (M)180mm (L)180mm (XL)210mm | |
| Seatpost Clamp: Intense Custom | |
| Saddle: WTB Silverado 265, Chromoly | |
| Grips: ODI Elite Flow Lock On |
Spec is subject to change based on availability.
FEATURES
Tazer Evolved
Cleaner lines, minimized logos, and a fresh, modern look that speaks for itself. A sleek carbon front triangle pairs seamlessly with a sculpted rear design, creating a frame that’s as visually striking.
Dual Co-Rotating Link Suspension
Our Dual Co-Rotating Link (DCR) suspension keeps the chassis low, calm, and planted, so the bike tracks the ground and gives you incredible cornering traction, yet still feels playful, and highly active when you push into the trail.
Bosch Performance Line CX Gen 5
With 120nm of max torque and 750w of peak power, the BOSCH performance line cx drive unit delivers up to 600% motor support.
FRAME PROTECTION
Integrated frame protection keeps the front and rear triangle looking new, while a built-in rear fender helps shield the shock from dirt and debris.
Full Water Bottle & Accessory Mount
Equipped with a full water bottle and accessory mount under the top tube gives you a secure place to carry tools, air canisters, tire irons, and other essentials.
MX & 29" Configuration
Available in MX or full 29” rear triangle configurations. The Tazer is suited to match your riding style.
