| Frame Size | SM | MD | LG | XL |
| Reach | 430mm | 455mm | 475mm | 505mm |
| Headtube Angle | 65° | 65° | 65° | 65° |
| Seattube Angle (Effective) | 78° | 78° | 78° | 78° |
| Seattube Angle (Actual) | 74° | 74° | 74° | 74° |
| Wheelbase | 1177mm | 1206mm | 1230mm | 1264mm |
| Chainstay Length | 435mm | 435mm | 435mm | 435mm |
| Front Center | 742mm | 771mm | 800mm | 829mm |
| BB Height | 336mm | 336mm | 336mm | 336mm |
| Stack | 602mm | 612mm | 620mm | 630mm |
| Toptube Length | 557mm | 585mm | 607mm | 639mm |
| Headtube Length | 100mm | 110mm | 120mm | 130mm |
| BB Drop | 38.5mm | 38.5mm | 38.5mm | 38.5mm |
| Seattube Length | 390mm | 415mm | 440mm | 465mm |
| Max Seatpost Insertion Depth | 215mm | 250mm | 275mm | 300mm |
*Based off a 537mm axle to crown, 44mm offset fork // **Based off front tire OD of 750mm, rear tire OD of 750mm
| Model Year: 2026 |
| Category: Trail |
| Available Sizes: S, M, L, XL |
| Available Colors: Oxblood Red, Satin Gray, & Chalk White |
| Frame Weight (No Shock): (S) 5 lbs 12 oz / 2.61 kg | (M) 6 lbs / 2.72 kg | (L) 6 lbs 3 oz / 2.80 kg | (XL) 6 lbs 6 oz / 2.89 kg |
| Headset: ZS44 Upper / ZS56 Lower |
| Seattube Diameter: 31.6mm |
| Seatpost Clamp: 36.4mm |
| Max Seatpost Insertion Depth: (S) 215mm | (M) 250mm | (L) 275mm | (XL) 300mm |
| BB Shell Width: BSA 73mm |
| Rear Hub Spacing: 148mm x 12mm Thru-Axle Boost |
| Max Front Travel: 130mm |
| Max Rear Travel: 130mm |
| Non-Compatible Shocks: All Coils | FOX Live Valve, X2 | RockShox Flight Attendant, Vivid Air |
| Shock Size: 210mm x 50mm |
| Front Shock Mount Hardware: 8mm x 30mm |
| Rear Shock Mount Hardware: 8mm x 20mm |
| Max Chainring: 34T |
| Chainline: 52mm Shimano 12S | 52mm SRAM Eagle 12S | 55mm SRAM T-Type 12S |
| Derailleur Hanger: UDH |
| T-Type Compatible: Yes |
| Recommended Max Tire Width: 2.5" |
| Brakes: Disc Brake Hydraulic, Post Mount / Direct |
| Min Rotor Size: 180mm |
| Max Rotor Size: 203mm (with adapter) |
| Frame | Material: Size-Specific Carbon Layup |
| Wheel Size: Full 29" Platform | |
| Front/Rear Travel: 130mm / 130mm | |
| Derailleur Hanger: UDH | |
| T-Type Compatible: Yes | |
| Cable Routing: Fully guided internal | |
| Bottom Bracket: Threaded BSA | |
| Accessory Mount: Integrated mount under top tube | |
| Frame Protection: Custom molded protection | |
| Rear Fender: Integrated | |
| Suspension | Fork: FOX Factory 36 SL, 29in, 130, Grip X, HSC, LSC, LSR, 15QRx110, 44mm offset |
| Shock: FOX Float Factory, 2pos-Adj, Evol LV, 210x50 | |
| Drivetrain | Derailleur: Shimano XT Di2 RD-M8250-SGS, 12-Speed, Long Cage |
| Cassette: Shimano XT CS-M8200, 10-51 | |
| Crankset: Shimano XT FC-M8200, 32t, 165mm Length | |
| Shifter: Shimano XT Di2 SW-M8250 | |
| Bottom Bracket: Shimano XT MT800, Threaded | |
| Chain: Shimano XT CN-M8100 12 Speed | |
| Wheels | Wheelset: DT Swiss XM 1700 |
| Front Hub: DT Swiss 350 | |
| Rear Hub: DT Swiss 350 | |
| Tires: Maxxis Forekaster 29x2.40 3C/EXO/TR | |
| Brakes | Brakeset: Shimano XT M8220 |
| Rotor: Shimano XT SM-RT86, 6 Bolt, Ice-Tech, 203mm | |
| Components | Headset: Acros ZS44 Upper / ZS56 Lower |
| Stem: Renthal Apex, 35mm x 40mm, Black/Alu Gold | |
| Handlebar: Renthal Fatbar Carbon, 35, 30mm Rise, 800mm Length | |
| Seatpost: OneUp V3 Dropper Post (S) 150mm (M) 180mm (L) 180mm (XL) 210mm | |
| Seatpost Clamp: Intense 36.4mm | |
| Saddle: WTB Volt Med Fusion Form Titanium Blk | |
| Grips: ODI Elite Flow Lock-On | |
| Pro Build Weight | Medium Frame Pro Build: 29lbs 5oz / 13.30kg |
FEATURES
Dual Co-Rotating Link Suspension
Our Dual Co-Rotating Link (DCR) suspension keeps the chassis low, calm, and planted, so the bike tracks the ground and gives you incredible cornering traction, yet still feels playful, and highly active when you push into the trail.
Internal Cable Routing
Fully internal cable routing keeps the frame clean, organized, and quiet while protecting your cables from wear and the elements.
Threaded BB
The Spider’s threaded bottom bracket is the preferred choice for maintenance-minded riders, offering reliable, creak-free performance over the long haul.
Frame Protection
Integrated frame protection keeps the front and rear triangle looking new, while a built-in rear fender helps shield the shock from dirt and debris.
Carbon Fit
The Spider’s carbon layup is optimized for each frame size to deliver the ideal balance of stiffness, strength, and compliance for riders of all sizes. This ensures consistent responsiveness and performance across the entire size range.
Accesory Mount
An integrated accessory mount under the top tube gives you a secure place to carry tools, air canisters, tire irons, and other essentials.
