Name: TAZER FOX EXPERT
Brand: EBIKE / Mullet (27.5"+29") / 155mm
SKU: 23ZCE7EXPM-TAN-FJM-NA
Price: 5299.0 USD
Availability: OutOfStock

$7,099.00 $5,299.00

(1)

With 160/155mm of front/rear wheel travel and Shimano’s powerful STEPS E7000 motor system, the Tazer is our high-performance Enduro eBike.

Size

SM

MD

LG

XL

Loading Product Locator

With 160/155mm of front/rear wheel travel and Shimano's powerful STEPS motor system E7000, the Tazer is our high-performance Enduro eBike. With a bump-eating 29" wheel up front and traction-seeking 27.5+" in the rear, you get excellent handling, fantastic grip, and trail ride excellence. With our Tazer, you'll never look at mountain biking the same way ever again.

	BUILD	EXPERT
	WEIGHT	48 lbs 15 oz // 22.197 kg
	FRAME	Tazer Performance E Monocoque carbon frame. Optimized layup carbon fiber. Alloy top link, internal shift, Dropper Post, Brake, Display unit routing, E*Spec Chainguide mount pattern, Flak guard armor, Integrated mud guard, 155mm Travel.
	MOTOR	Shimano Steps E7000 25KM/H 250W 60Nm Torque
	BATTERY	BT-E8010, FOR STEPS, 504Wh. Battery lock w/2 keys
	DISPLAY UNIT	Shimano SC-E7000 Display/Cycle Computer, 35mm Clamp Band Diameter
	FORK	FOX Performance Float 38, 29", 160mm, GRIP Damper, 51mm Offset
	SHOCK	FOX Float X Performance 185x55 2Pos on SM/MD/LG, FOX Float X2 Performance 185x55 2Pos on XL
	WHEELSET	ethirteen espec Plus 30mm 29" (front), ethirteen espec Plus 35mm 27.5" (rear)
	HUBS	INTENSE E-MTN
	TIRES	MAXXIS Minion DHR II MAXX Terra 3C Exo + - 29" x 2.60" Front, 27.5" x 2.80" Rear
	SHIFTER	Shimano Deore 12-speed
	DERAILLEUR	Shimano Deore 12-speed
	CRANK	ethirteen espec 34 Tooth Chainring 165mm length
	CASSETTE	Shimano Deore 12-speed / 11-51T
	CHAIN	Shimano Deore 12-speed
	SADDLE	SDG Bel-Air V3
	SEATPOST	INTENSE Recon Dropper 31.6mm (SM 125mm, MD 150mm, LG-XL 170mm)
	HANDLEBAR	e*thirteen Base 35 800mm
	STEM	e*thirteen Base 35 40mm
	BRAKESET	Shimano M6120 w/ 203mm RT-66 Rotors
	GRIPS	INTENSE Lock-On

SIZE	SM	MD	LG	XL
WHEELBASE	1204 MM / 47.4"	1234 MM / 48.6"	1264 MM / 49.8"	1294 MM / 50.95"
TOPTUBE LENGTH	580 MM / 22.8"	609 MM / 24"	637 MM / 25"	667 MM / 26.3"
CHAINSTAY LENGTH	450 MM / 17.7"	450 MM / 17.7"	450 MM / 17.7"	450 MM / 17.7"
HEADTUBE LENGTH	100 MM / 3.94"	115 MM / 4.5"	125 MM / 4.9"	125 MM / 4.9"
HEADTUBE ANGLE	64.5˚	64.5˚	64.5˚	64.5˚
REACH	414 MM / 16.3"	438.5 MM / 17.26"	464 MM / 18.3"	494 MM / 19.5"
STACK	617 MM / 24.3"	631 MM / 24.9"	640.5 MM / 25.2"	641 MM / 25.2"
BB HEIGHT	350 MM / 13.8"	350 MM / 13.8"	350 MM / 13.8"	350 MM / 13.8"
BB DROP	8.3 MM / 0.33"	8.3 MM / 0.34"	8.3 MM / 0.34"	8.3 MM / 0.35"
SEATTUBE ANGLE (EFFECTIVE)	74.9˚	74.9˚	74.9˚	74.9˚
SEATTUBE ANGLE (ACTUAL)	72.5˚	72.5˚	72.5˚	72.5˚
SEATTUBE LENGTH	394 MM / 15.5"	419 MM / 16.5"	445 MM / 17.5"	470 MM / 18.5"
STANDOVER HEIGHT	809 MM / 31.8"	816 MM / 32"	824 MM / 32.4"	836 MM / 32.9"
FORK AXLE TO CROWN	577.7 MM / 22.7"	577.7 MM / 22.7"	577.7 MM / 22.7"	577.7 MM / 22.7"
LOWER HEADSET STACK HEIGHT	4 MM / 0.16"	4 MM / 0.16"	4 MM / 0.16"	4 MM / 0.16"
FORK OFFSET	51 MM / 2"	51 MM / 2"	51 MM / 2"	51 MM / 2"
FORK TRAIL	122 MM / 4.8"	122 MM / 4.8"	122 MM / 4.8"	122 MM / 4.8"
FORK TRAVEL	160 MM / 6.3"	160 MM / 6.3"	160 MM / 6.3"	160 MM / 6.3"
REAR TRAVEL	155 MM / 6.1"	155 MM / 6.1"	155 MM / 6.1"	155 MM / 6.1"
REAR SHOCK SIZE	185 x 55	185 x 55	185 x 55	185 x 55
FRONT CENTER	754 MM / 29.7"	785 MM / 30.9"	814 MM / 32.1"	844 MM / 33.2"
BB HEIGHT BASED ON FRONT TIRE OD	749.3 MM / 29.5"	749.3 MM / 29.5"	749.3 MM / 29.5"	749.3 MM / 29.5"
BB HEIGHT BASED ON REAR PLUS TIRE OD	717.55 MM / 28.25"	717.55 MM / 28.25"	717.55 MM / 28.25"	717.55 MM / 28.25"

RIDE FARTHER. RIDE FASTER.

With 160/155mm of front/rear wheel travel and Shimano's powerful STEPS motor system EP800, the Tazer is our high-performance Enduro eBike. With a bump-eating 29" wheel up front and traction-seeking 27.5+ on the back.

EXPLORE NEW TERRITORY

Our Tazer opens up a new world and style of riding, where the ups are almost as much fun as the downs. What once might have been a tedious slog or just a means to an end can now be a technical challenge or a quick spin to get you to the top and all the fun bits again.

ENJOY THE ASCENTS, CRUSH THE DESCENTS

You will eat up laps at your local trail loops, maximizing your time on your bike. You can do three or four times the amount of riding you normally do on a non-eBike, maximizing your skills on the descents. The beauty of the Tazer is that you can go as hard or as easy as you like.

THE JS TUNED ENDURO LINK

We talk a lot about JS Tuned here at INTENSE. JS stands for Jeff Steber (our founder and CEO), and simply put, it is a system that focuses on all of the individual parts that make up one of our bikes: from suspension, geometry, wheel size, materials, and component spec.
